Avalue EMX-965GME 08GSA965GM1303 Core 2 Duo Mini ITX Motherboard
Avalue Core 2 Duo Mini ITX Motherboard
Model: EMX-965GME
P/N: 08GSA965GM1303
- Motherboard Specifications:
- CPU
- Supports Intel socket P Core Duo / Core Solo / Core 2 Duo CPU with 65nm process technology
- FSB
- 533/800 MHz
- BIOS
- Award 2 MB SPIROM
- System Chipset
- Intel GME965 / ICH8M-M
- I/O Chip
- Winbond W83627DHG-A
- System Memory
- Two 200-pin SODIMM sockets support up to 4 GB Dual Channel DDR2 533/667 SDRAM
- SSD
- One CompactFlash Type I/II socket
- Expansion
- 1 PCI (PCI Rev. 2.2 compliant) supports 3 PCI master
- I/O
- MIO
- 1 x EIDE, 3 x SATA, 1 K/B, 1 MS, 4 RS-232 (5V/12V)
- USB
- 10 x USB 2.0
- TPM
- TPM 1.2 (Infineon SLB 9635 TCG 1.2)
- DI/O
- 8-bit General Purpose I/O for DI and DO
- Chipset
- Intel® GME965 integrated Graphics Media Accelerator X3100
- Display Memory
- Intel® DVMT 4.0 supports 384 MB video memory
- Resolution
- 2048 x 1536 @ 32 bpp (60Hz)
- Multiple Display
- CRT + LVDS, or CRT + DVI-D
- LVDS
- Dual-channel 24-bit LVDS
- DVI
- Chrontel CH7307C DVI transmitter up to 165M pixels/second
- Audio
- Chipset
- Intel ICH8-M
- AC97 Codec
- Realtek ALC888 HD Audio Codec supports 5.1+2-CH audio streams
- Audio Interface
- Mic in, Line in, (CD Audio in), Line out
- Ethernet
- LAN
- Dual Realtek RTL8111B PCIe Gigabit Ethernet Controller
- Size ( L x W )
- 6.69" x 6.69" (170 mm x 170 mm)
- Package Includes
- Motherboard
- I/O Plate
| MPN | EMX-965GME |
|---|---|
| Price View | Price Range |
| Manufacturer | Avalue |
| Form Factor | Mini ITX |
| Features | On-Board Audio, On-Board Video Chipset |
| Condition | Certified Refurbished (Excellent) |
| Condition Comment | Full working order |
| Warranty | 12 Month Warranty |
| Important | It is your responsibility as a buyer to ensure this is compatible with your hardware or operating system before buying. Assume that any photo is a library photo, not the actual item you will receive, unless expressly mentioned above. Unless expressly mentioned in the description, there will be no other parts included with the item. This includes items such as drivers, cables, manuals, warranty cards etc. Hard drives, tape drives, caddies etc. will not include any screws, fixing rails unless expressly mentioned. |
